Mini PC ACTINA NUC i5-1340P/8GB/256SSD/W11Pro

Technical Specifications

Processor

Built-in processor: Yes

Processor manufacturer: Intel

Processor cores: 12

Processor codename: Raptor Lake

Processor model: i5-1340P

Processor threads: 16

Processor cache: 12 MB

Performance-core boost frequency: 4.6 GHz

Processor family: Intel® Core™ i5

Performance cores: 4

Graphics

Number of displays supported: 4

On-board graphics card model: Intel Iris Xe Graphics

On-board graphics card: No

Graphics card family: Intel

Maximum resolution: 7680 x 4320 pixels

:

:

:

:

:

:

:

:

:

:

Memory

Memory layout (slots x size): 1 x 8 GB

Memory slots type: SO-DIMM

Memory voltage: 1.2 V

Number of memory slots: 2

Number of DIMM slots: 2

Internal memory: 8 GB

Supported memory types: DDR4-SDRAM

ECC: No

Memory channels: Dual-channel

Non-ECC: Yes

Design

Product codename: Arena Canyon

Product family: Intel NUC

Product type: Mini PC

Chassis type: Nettop

Cooling type: Active

On/off switch: Yes

LED indicators: Yes

Product colour: Black

:

:

Power

Power supply type: External AC adapter

:

:

:

:

:

:

:

:

:

Weight & dimensions

Depth: 112 mm

Width: 117 mm

Height: 37 mm

:

:

:

:

:

:

:

Network

WLAN controller model: Intel Wi-Fi 6E AX211

Bluetooth version: 5.3

Ethernet LAN: Yes

Top Wi-Fi standard: Wi-Fi 6E (802.11ax)

Wi-Fi: Yes

Wi-Fi standards: Wi-Fi 6E (802.11ax)

LAN controller: Intel I226-V

Bluetooth: Yes

:

:

Performance

Operating system installed: Windows 11 Pro

Motherboard form factor: UCFF

:

:

:

:

:

:

:

:

Packaging content

Power cord included: Yes

:

:

:

:

:

:

:

:

:

Expansion slots

Number of M.2 (M) slots: 1

PCI Express slots version: 4.0

:

:

:

:

:

:

:

:

Processor special features

Execute Disable Bit: Yes

Intel® Platform Trust Technology (Intel® PTT): Yes

Intel ME Firmware Version: 16.1

Intel Virtualization Technology for Directed I/O (VT-d): Yes

Intel Virtualization Technology (VT-x): Yes

Intel Flex Memory Access: Yes

Intel® AES New Instructions (Intel® AES-NI): Yes

Intel® Optane™ Memory Ready: No

Intel VT-x with Extended Page Tables (EPT): Yes

Intel Trusted Execution Technology: Yes

Audio

Built-in speaker(s): No

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

Storage

SSD form factor: M.2

NVMe: Yes

Number of storage drives installed: 1

Storage drive interface: PCI Express, Serial ATA

Total storage capacity: 256 GB

Storage drive sizes supported: M.2

Storage media: SSD

Number of storage drives supported: 2

Supported storage drive types: SSD

:

Ports & interfaces

USB ports quantity: 4

M.2 card slot (wireless): 2230 (E-key) (E)

Combo headphone/mic port: Yes

USB 2.0 ports quantity: 1

M.2 card slot (storage): 2280 NVMe (M); 2242 SATA (B)

Number of SATA III connectors: 1

Ethernet LAN (RJ-45) ports: 1

HDMI version: 2.1

Serial port via internal header: No

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3

Other features

DC input voltage: 12 – 20 V

Additional headers: Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby); Internal 2×2 power connector

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:
