Lenkeng HDMI Matrix over IP 1080p Receiver LKV383Matrix-RX

The Lenkeng LKV383Matrix-RX is a 1080p HDMI over IP receiver, part of an HDMI matrix system that transmits and distributes HDMI signals over a local network (LAN) using IP (Internet Protocol) technology. This allows for flexible, long-distance AV distribution without traditional HDMI cable limitations.

• Full HD 1080p Support – Transmits high-definition video and audio over IP.
• HDMI over IP (H.264/H.265 Encoding) – Compresses and streams HDMI signals via Ethernet.
• LAN/Wi-Fi Connectivity – Uses CAT5e/6/7 cables or Wi-Fi (if supported) for transmission.
• Low Latency – Optimized for real-time video (gaming, live broadcasts, etc.).
• IR Remote Pass-Through – Control source devices remotely via IR extender.
• Multi-Room Distribution – Works with a transmitter (TX) to send signals to multiple receivers (RX).
• Plug-and-Play – No software needed for basic setup.

—

 Video & Audio

• Supported Resolution:

  • 1080p Full HD (1920×1080 @ 60Hz)

  • Lower resolutions supported (720p, 480p)

• Video Compression: H.264 (AVC) encoding

• Color Depth: 8-bit (16.7 million colors)

• Audio Support:

  • HDMI embedded audio (LPCM, Dolby Digital, DTS)

  • Stereo 2.0 / 5.1 Surround (depends on source)

Network & Connectivity

• Transmission Method: HDMI over IP (LAN/Wi-Fi)

• Ethernet Port: 10/100Mbps (RJ45)

• Wi-Fi Support: Likely optional (depends on firmware)

• Latency: <100ms (near real-time)

• Max Transmission Distance:

  • Up to 100m (328ft) via CAT6 Ethernet

  • Longer distances possible with network switches

Ports & Power

• HDMI Output: 1× HDMI (to display)

• IR Remote Port: 3.5mm jack (for IR extender)

• Power Input: DC 5V/1A (USB or power adapter)

• USB Port: Possibly for firmware updates

 Compatibility

• HDCP Support: HDCP 1.4 (may not work with HDCP 2.2 content)

• Supported Devices:

  • PCs, laptops, gaming consoles (PS4, Xbox), Blu-ray players, cable boxes

  • Not compatible with Apple DRM-protected content (e.g., iTunes movies)

—
