Lenovo ThinkCentre neo 30s Gen 5 Intel® Core™ i5 i5-13420H 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro SFF PC Black, Grey

Technical Specifications

Processor

Efficient-core Max Turbo Frequency: 3.4 GHz

Processor base power: 45 W

Processor generation: 13th gen Intel® Core™ i5

Maximum turbo power: 115 W

Efficient cores: 4

Performance cores: 4

Performance-core Max Turbo Frequency: 4.6 GHz

Processor family: Intel® Core™ i5

Processor manufacturer: Intel

Processor model: i5-13420H

Graphics

On-board GPU manufacturer: Intel

Discrete graphics card model: Not available

On-board graphics card model: Intel® UHD Graphics

On-board graphics card: Yes

On-board graphics card family: Intel® UHD Graphics

Discrete graphics card: No

:

:

:

:

:

:

:

:

:

Memory

Memory slots: 2x SO-DIMM

Memory clock speed: 5200 MHz

Internal memory type: DDR5-SDRAM

Memory channels: Dual-channel

Maximum internal memory: 64 GB

Memory layout (slots x size): 1 x 16 GB

Internal memory: 16 GB

:

:

:

Design

Viewing window: No

Volume: 8.2 L

Colour name: Chassis: Black, Bezel: Grey

Placement supported: Vertical

Product colour: Black

Cable lock slot type: Kensington

Cable lock slot: Yes

Chassis type: SFF

:

:

Power

Power supply: 180 W

:

:

:

:

:

:

:

:

:

Operational conditions

Operating relative humidity (H-H): 20 – 80%

Operating temperature (T-T): 5 – 35 °C

Non-operating altitude: 0 – 12192 m

Storage temperature (T-T): -40 – 60 °C

Storage relative humidity (H-H): 10 – 90%

Operating altitude: 0 – 3048 m

:

:

:

:

Weight & dimensions

Height: 339.5 mm

Weight: 4.63 kg

Width: 92.5 mm

Depth: 291.7 mm

:

:

:

:

:

:

Network

WLAN controller model: Intel Wi-Fi 6 AX203

Bluetooth version: 5.2

WLAN controller manufacturer: Intel

Bluetooth: Yes

Top Wi-Fi standard: Wi-Fi 6 (802.11ax)

Wi-Fi standards: Wi-Fi 6 (802.11ax)

Ethernet LAN data rates: 1000 Mbit/s

Wi-Fi: Yes

Cabling technology: 10/100/1000Base-T(X)

Antenna type: 2×2

Performance

Password protection type: Power on

Password protection: Yes

Trusted Platform Module (TPM) version: 2.0

Built-in speaker(s): Yes

Motherboard chipset: Intel SoC

Trusted Platform Module (TPM): Yes

Product type: PC

:

:

:

Packaging data

Package depth: 395 mm

Package height: 530 mm

Package weight: 6.83 kg

Package width: 195 mm

:

:

:

:

:

:

Packaging content

Mouse connectivity: Wired

Keyboard included: Yes

Mouse included: Yes

:

:

:

:

:

:

:

Display

Display included: No

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

Software

Operating system language: Polish

Operating system installed: Windows 11 Pro

:

:

:

:

:

:

:

:

Audio

Number of speakers: 1

Audio system: High Definition Audio

Audio chip: Realtek ALC623-CG

:

:

:

:

:

:

:

Storage

NVMe: Yes

Number of SSDs installed: 1

SSD interface: PCI Express 4.0

SSD capacity: 512 GB

Total SSDs capacity: 512 GB

SSD form factor: M.2

Card reader integrated: No

Optical drive type: DVD±RW

Total storage capacity: 512 GB

Number of storage drives installed: 1

Ports & interfaces

Line-out: Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4

USB 2.0 ports quantity: 2

Ethernet LAN (RJ-45) ports: 1

VGA (D-Sub) ports quantity: 1

Combo headphone/mic port: Yes

HDMI ports quantity: 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1

Microphone in: Yes

HDMI version: 2.1

Keyboard

Keyboard connectivity: Wired

:

:

:

:

:

:

:

:

:

Sustainability

Sustainability certificates: TCO

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:
