Adastra MM321 Rack Mixer BT/USB/FM 953.028UK

SKU: 20543

€ 231,00

Brand	Adastra

Out of stock

Buy Now. Pay Later. Zero Interest.

Split your purchase into 6 or 12 easy monthly installments. Terms apply.

Combine your favourite device with 5G Unlimited Max Plus and get it with from €0 upfront and up to 24 installments.

Transfer your number to EPIC Contract Renewal Smartphone Anytime

T&Cs apply. Contact us at 77 77 06 12 or visit our store for more.

5G Max Value

Transfer from Pay Monthly
24 months contract Unlimited Minutes to all National Networks Unlimited SMS 5GB DATA

€21.62/mo

€0 UPFRONT COST

5G Unlimited Max

Transfer from Pay Monthly
24 months contract Unlimited Minutes to all National Networks Unlimited SMS Unlimited DATA

€29.62/mo

€0 UPFRONT COST

5G Unlimited Max Plus

Transfer from Pay Monthly
24 months contract Unlimited Minutes to all National Networks & 100 minutes to selected international destinations Unlimited SMS Unlimited DATA

€34.61/mo

€0 UPFRONT COST

Description

Rack-mountable 1U mixer with built-in media player and Bluetooth receiver. 3 mono inputs connect via XLR microphone or line input (switchable). Each of these inputs has switchable +20V phantom power for use with condenser microphones or D.I. boxes and channel 1 has a variable priority function. Two stereo auxiliary line inputs are provided on RCA connectors with a stereo record output. Media player operating modes include 3.5mm Aux input, USB audio player, FM radio tuner and Bluetooth receiver for playback from a smart phone or tablet. Main left and right outputs are fed to XLR with an additional mono summed output on 6.3 jack. Versatile yet easy to use as a main mixer for background music, public address and house PA systems.

Built-in Bluetooth receiver
Media player with USB playback and FM tuner
Switchable +20V phantom power
Variable priority muting for channel 1
24V emergency mute contacts

The box for this item contains:

MM321 1U mixer with Bluetooth + USB/FM player
IEC power lead(s)

Power supply: 100-240Vac, 50/60Hz (IEC)
Fuse: T1AL
Inputs: mic/line3 x XLR (bal/unbal)
Inputs: aux2 x L+R RCA
Input: line3.5mm jack to media player
Audio source: Internal Bluetooth, USB & FM player
Outputs: L+R XLR, Mono 6.3mm jack, Record out (RCA)
Emergency control: 24V contacts mute all except channel 1
Phantom power: +20V (switchable channels 1-3)
Controls: Media, 3 x Mic/Line, 2 x Aux, Treble, Bass, Master level
Rear panel controls: Priority muting level, mic/line and phantom DIP switches
Input impedance: 2.2k Ohms (mic/line), 10k Ohms (aux)
Frequency response: mic20Hz – 18kHz
Frequency response: line14Hz – 20kHz
Frequency response: aux10Hz – 23kHz
Input sensitivity: mic/line-45dBV
Input sensitivity: aux/line-10dBV
Signal to noise ratio: mic55dB
Signal to noise ratio: aux/line60dB
THD: 0.05%
Dimensions: 482 x 130 x 44mm
Weight: 1.43kg
