ASUS MESH ZenWiFi AX1800 Wi-Fi 6 Dual Band Gigabit XD4 Plus 3 Pack White

he ZenWiFi AX Mini system consists of one ASUS AX1800 WiFi 6 router and two extending node, featuring unique technologies that give you superfast, reliable and secure WiFi connections — inside or outside your home!

• Whole-home Coverage
• True 8K Streaming – * Compatible WiFi 6 device required.
• Space-saving and Great Design
• More Stable WiFi with Wired Connections between ZenWiFi Hubs

—

General Information

• Device Type: Wi-Fi 6 Mesh System (3 routers included)

• Enclosure Type: Desktop

• Color: White

• Status Indicators: Power LED

Wireless Specifications

• Wi-Fi Standard: Wi-Fi 6 (802.11ax)

• Wi-Fi Rating: AX1800 (574 Mbps @2.4GHz + 1201 Mbps @5GHz)

• Frequency Bands: Dual-band (2.4GHz & 5GHz)

• Antennas: 2 internal antennas per unit

• MU-MIMO: Yes (2×2 dual-stream)

• AiMesh Support: Yes (seamless whole-home coverage)

Performance & Coverage

• Max Coverage (3-Pack): Up to 4,800 sq.ft

• Max Data Rates:

  • 5GHz (802.11ax): 1201 Mbps

  • 2.4GHz (802.11ax): 574 Mbps

  • 802.11ac: 867 Mbps

• Supported Protocols: 802.11a/b/g/n/ac/ax

Security & Networking

• Encryption: WPA3-Personal, WPA2-Personal, WPA-Enterprise

• VPN Support: OpenVPN, PPTP, L2TP, IPSec

• Firewall & Protection:

  • AiProtection Classic (malware blocking)

  • Parental Controls

  • Guest Network

  • IPv4/IPv6 Support

Ports & Connectivity

• Ethernet Ports per Unit:

  • 1 × Gigabit WAN

  • 1 × Gigabit LAN

• USB Port: None

• Wireless Backhaul: Yes (for mesh setup)

Hardware & Power

• Processor: Quad-core 1.5GHz

• Memory: 256MB RAM / 128MB Flash

• Power Supply: External adapter (100-240V, 50/60Hz)

• Weight per Unit: 307g

Management & Features

• Mobile App: ASUS Router App (iOS/Android)

• Voice Control: Alexa compatible

• Advanced Features:

  • QoS (Quality of Service)

  • Port Forwarding / Triggering

  • DMZ Support

  • Bandwidth Monitor

Environmental & Included Accessories

• Operating Temperature: 0°C to 40°C

• Included in Box:

  • 3 × ASUS XD4 Routers

  • 3 × Power Adapters

  • 1 × Ethernet Cable

  • Quick Start Guide

—
