DELL Pro Max 14 MC14250 Intel Core Ultra 7 265H Mobile workstation 35.6 cm (14") Full HD+ 16 GB LPDDR5x-SDRAM 512 GB SSD Wi-Fi 7 (802.11be) Windows 11 Pro UK International Black

Technical Specifications

Processor

Processor cores: 16

Processor model: 265H

Processor threads: 16

Processor boost frequency: 5.3 GHz

Efficient-core Max Turbo Frequency: 4.5 GHz

Performance-core Max Turbo Frequency: 5.3 GHz

Processor manufacturer: Intel

Processor family: Intel Core Ultra 7

Processor cache: 24 MB

Processor generation: Intel Core Ultra (Series 2)

Graphics

On-board graphics card model: Intel Arc 140T

Discrete graphics card model: Not available

Discrete graphics card: No

On-board GPU manufacturer: Intel

On-board graphics card family: Intel Arc Graphics

On-board graphics card: Yes

:

:

:

:

:

:

:

:

:

Memory

Internal memory: 16 GB

Memory channels: Dual-channel

Memory form factor: LPCAMM

Internal memory type: LPDDR5x-SDRAM

Memory data transfer rate: 7467 MT/s

Memory layout (slots x size): 1 x 16 GB

Non-ECC: Yes

Maximum internal memory: 64 GB

:

:

Design

Product type: Mobile workstation

Intel® vPro™ Platform Eligibility: Yes

Product colour: Black

:

:

:

:

:

:

:

Power

USB Type-C charging port: Yes

USB Type-C required charging power (max): 71 W

USB Type-C required charging power (min): 45 W

USB Power Delivery (USB PD): Yes

AC adapter frequency: 50/60 Hz

AC adapter power: 100 W

AC adapter input voltage: 100 – 240 V

:

:

:

Security

Cable lock slot: Yes

Fingerprint reader: Yes

Cable lock slot type: Wedge

Smart card reader: Yes

Trusted Platform Module (TPM) version: 2.0

Windows Hello: Yes

Trusted Platform Module (TPM): Yes

:

:

:

Operational conditions

Storage relative humidity (H-H): 0 – 95%

Storage temperature (T-T): -40 – 65 °C

Operating shock: 110 G

Operating altitude: -15.2 – 3048 m

Operating vibration: 0.66 G

Operating temperature (T-T): 0 – 35 °C

Non-operating altitude: -15.2 – 10668 m

Operating relative humidity (H-H): 10 – 90%

Non-operating vibration: 1.3 G

Non-operating shock: 160 G

Weight & dimensions

Height (front): 1.48 cm

Depth: 227.3 mm

Weight: 1.83 kg

Width: 313 mm

Height (rear): 1.89 cm

:

:

:

:

:

Network

Ethernet LAN data rates: 100

Wi-Fi data rate (max): 5760 Mbit/s

Wi-Fi standards: Wi-Fi 6E (802.11ax)

Ethernet LAN: Yes

WLAN controller model: Intel Wi-Fi 7 BE201

Mobile network connection: No

Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz)

WLAN controller manufacturer: Intel

Top Wi-Fi standard: Wi-Fi 7 (802.11be)

Antenna type: 2×2

Performance

Hall sensor: Yes

Accelerometer: Yes

Motherboard chipset: Intel SoC

:

:

:

:

:

:

:

Packaging content

AC adapter included: Yes

:

:

:

:

:

:

:

:

:

Display

Pixel density: 162 ppi

HD type: Full HD+

Native aspect ratio: 16:10

Touchscreen: No

RGB colour space: NTSC

Colour gamut:

Colour gamut: 45%

Contrast ratio (typical): 800:1

Display resolution: 1920 x 1200 pixels

Panel type: WVA

Display brightness: 300 cd/m²

Display response rise/fall: 35 ms

Maximum refresh rate: 60 Hz

Anti-glare screen: Yes

LED backlight: Yes

Display diagonal: 35.6 cm (14")

Software

Operating system architecture: 64-bit

Trial software: McAfee® Business Protection 1-year (Disti Only),No Microsoft Office License included (Fed and Premier, Exception Only)

Operating system installed: Windows 11 Pro

:

:

:

:

:

:

:

Audio

Audio chip: Realtek ALC3329

Number of microphones: 2

Audio system: MaxxAudio Pro

Speaker power: 2 W

Speakers manufacturer: Waves

Built-in microphone: Yes

Number of built-in speakers: 2

:

:

:

Storage

SSD interface: PCI Express 4.0

Total storage capacity: 512 GB

Storage media: SSD

Total SSDs capacity: 512 GB

Optical drive type: No

M.2 SSD size: 2230 (22 x 30 mm)

SSD capacity: 512 GB

NVMe: Yes

SSD form factor: M.2

SSD performance class: 35

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1

HDMI version: 2.1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2

USB Type-C DisplayPort Alternate Mode: Yes

HDMI ports quantity: 1

Combo headphone/mic port: Yes

Thunderbolt 4 ports quantity: 2

PowerShare: Yes

Intel® Thunderbolt 4: Yes

:

Camera

Front camera resolution (numeric): 2.07 MP

Infrared (IR) camera: Yes

Front camera: Yes

Front camera HD type: Full HD

Video capturing speed: 30 fps

Front camera resolution: 1920 x 1080 pixels

:

:

:

:

Battery

Battery voltage: 15.6 V

Number of battery cells: 4

Battery capacity: 72 Wh

Battery technology: Lithium Polymer (LiPo)

Fast charging: Yes

Battery recharge time: 3 h

Battery weight: 270 g

:

:

:

Keyboard

Copilot key: Yes

Numeric keypad: No

Pointing device: Touchpad

Keyboard backlit: Yes

:

:

:

:

:

:

Brand-specific features

Brand specific technologies: Control Vault 3+, Express Charge Boost capable

:

:

:

:

:

:

:

:

:

Carbon footprint

Carbon emissions, end-of-life (kg of CO2e): 1.01

Carbon emissions, energy usage (kg of CO2e): 22.02

Carbon emissions, logistics (kg of CO2e): 5.25

PAIA version: GaBi version 1, 2024

Carbon emissions, manufacturing (kg of CO2e): 72.62

Total carbon footprint (kg of CO2e): 101

:

:

:

:

Neural processor unit (NPU)

Total processor performance up to: 97 TOPs

GPU performance up to: 75 TOPs

Windows Studio effects support: Yes

AI software frameworks supported by NPU: OpenVINO

Sparsity support: Yes

NPU performance up to: 13 TOPs

Neural processor unit (NPU): Intel AI Boost

:

:

:

:

:

:

:

:

:

:

:

:

:

:
