Lenovo ThinkPad X9-15 Gen 1 Copilot+ PC Intel Core Ultra 5 228V Laptop 38.9 cm (15.3") 2.8K 32 GB LPDDR5x-SDRAM 512 GB SSD Wi-Fi 7 (802.11be) Windows 11 Pro English Grey

Technical Specifications

Processor

Processor threads: 8

Processor model: 228V

Processor cache: 8 MB

Processor cache type: Smart Cache

Processor family: Intel Core Ultra 5

Processor cores: 8

Processor boost frequency: 4.5 GHz

Performance-core Max Turbo Frequency: 4.5 GHz

Performance cores: 4

Performance-core base frequency: 2.1 GHz

Graphics

Discrete graphics card model: Not available

On-board graphics card model: Intel Arc Graphics 130V

On-board graphics card family: Intel Arc Graphics

On-board GPU manufacturer: Intel

Discrete graphics card: No

On-board graphics card: Yes

:

:

:

:

:

:

:

:

:

Memory

Maximum internal memory: 32 GB

Internal memory type: LPDDR5x-SDRAM

Memory clock speed: 8533 MHz

Memory form factor: On-board

Internal memory: 32 GB

Memory channels: Dual-channel

:

:

:

:

Design

Product colour: Grey

Housing material: Aluminium

Intel® vPro™ Platform Eligibility: Yes

Product type: Laptop

:

:

:

:

:

:

Power

USB Type-C charging port: Yes

AC adapter input voltage: 100 – 240 V

AC adapter power: 65 W

USB Power Delivery (USB PD): Yes

AC adapter frequency: 50 – 60 Hz

:

:

:

:

:

Security

Trusted Platform Module (TPM): Yes

Password protection: Yes

Smart card reader: No

Fingerprint reader: Yes

Trusted Platform Module (TPM) version: 2.0

Windows Hello: Yes

:

:

:

:

Operational conditions

Operating relative humidity (H-H): 8 – 95%

Storage temperature (T-T): 5 – 43 °C

Storage relative humidity (H-H): 5 – 95%

Operating temperature (T-T): 5 – 35 °C

Maximum shipping altitude: 3048 m

:

:

:

:

:

Weight & dimensions

Weight: 1.4 kg

Height: 12.9 mm

Width: 339.6 mm

Depth: 228.5 mm

:

:

:

:

:

:

Network

Bluetooth: Yes

Antenna type: 2×2

Mobile network connection: No

Near Field Communication (NFC): No

Top Wi-Fi standard: Wi-Fi 7 (802.11be)

WLAN controller manufacturer: Intel

WWAN: Not installed

WLAN controller model: Intel Wi-Fi 7 BE201

Ethernet LAN: No

Wi-Fi standards: Wi-Fi 7 (802.11be)

Performance

Motherboard chipset: Intel SoC

:

:

:

:

:

:

:

:

:

Packaging content

AC adapter included: Yes

:

:

:

:

:

:

:

:

:

Display

Display diagonal: 38.9 cm (15.3")

Display resolution: 2880 x 1800 pixels

HD type: 2.8K

LED backlight: Yes

Native aspect ratio: 16:10

RGB colour space:

RGB colour space: DCI-P3

Touchscreen: No

Anti-reflective coating: Yes

High Dynamic Range (HDR) supported: Yes

High Dynamic Range (HDR) technology: Dolby Vision

Colour gamut: 100%

Contrast ratio (typical): 100000:1

Display brightness: 500 cd/m²

Maximum refresh rate: 120 Hz

Panel type: OLED

Software

Operating system architecture: 64-bit

Operating system language: Polish

Microsoft Copilot: Yes

Operating system installed: Windows 11 Pro

:

:

:

:

:

:

Audio

Built-in microphone: Yes

Audio chip: Cirrus Logic CS42L43

Audio system: Dolby Atmos

Number of microphones: 2

Speaker power: 2 W

Number of built-in speakers: 4

:

:

:

:

Certificates

Compliance certificates: RoHS

:

:

:

:

:

:

:

:

:

Storage

Total storage capacity: 512 GB

Optical drive type: No

Card reader integrated: No

M.2 SSD size: 2242 (22 x 42 mm)

Number of SSDs installed: 1

Storage media: SSD

Total SSDs capacity: 512 GB

SSD interface: PCI Express 4.0

SSD memory type: TLC

SSD form factor: M.2

Ports & interfaces

Combo headphone/mic port: Yes

USB Sleep-and-Charge: Yes

USB Sleep-and-Charge ports: 1

Thunderbolt 4 ports quantity: 2

Intel® Thunderbolt 4: Yes

HDMI version: 2.1

HDMI ports quantity: 1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1

USB Type-C DisplayPort Alternate Mode: Yes

:

Camera

Front camera: Yes

Front camera HD type: Ultra HD

Front camera resolution (numeric): 8 MP

Infrared (IR) camera: Yes

:

:

:

:

:

:

Battery

Battery capacity: 80 Wh

Battery technology: Lithium Polymer (LiPo)

:

:

:

:

:

:

:

:

Keyboard

Pointing device: Touchpad

Copilot key: Yes

Keyboard backlit: Yes

Spill-resistant keyboard: Yes

Numeric keypad: No

:

:

:

:

:

Neural processor unit (NPU)

GPU performance up to: 53 TOPs

Copilot+ PC: Yes

Total processor performance up to: 97 TOPs

AI software frameworks supported by NPU: ONNX RT

NPU performance up to: 40 TOPs

Neural processor unit (NPU): Intel AI Boost

Windows Studio effects support: Yes

Sparsity support: Yes

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:

:
