Dahua HDCVI 2.0MP Bullet 3.6mm HFW1200CL-IL-A-S6

* In order to use the Smart Dual Light HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000004.1.R.220323 or later version.

• Max. 30 fps@1080p
• 3D NR
• Smart Dual Light
• 20 m illumination distance
• Super Adapt
• Built-in mic
• 3.6 mm fixed lens
• CVI/CVBS/AHD/TVI switchable.
• IP67, 12 VDC

—

Camera

• Image Sensor : 2 MP CMOS
• Max. Resolution : 1920 (H) × 1080 (V)
• Scanning System : Progressive
• Electronic Shutter Speed : PAL: 1/25 s–1/100000 s / NTSC: 1/30 s–1/100000 s
• Min. Illumination : 0.01 [email protected] (Color, 30 IRE) / 0.001 [email protected] (B/W, 30 IRE) / 0 lux (Illuminator on)
• S/N Ratio : >65 dB
• Illumination Distance : IR: 20 m / Warm light: 20 m
• Illuminator On/Off Control : Auto
• Illuminator Number : 2 (Warm light);2 (IR light)

Lens

• Lens Type : Fixed-focal
• Auto Focus : No
• Lens Mount : M12
• Focal Length : 3.6 mm
• Max. Aperture : F2.0
• Field of View : 3.6 mm: H: 83°; V: 48°; D: 105°
• Iris Control : Fixed
• Close Focus Distance : 3.6 mm: 0.7 m

Video

• Video Frame Rate : CVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps; / AHD:
• PAL: 1080p@25 fps; NTSC: 1080p@30 fps; / TVI:  PAL: 1080p@25 fps; NTSC: 1080p@30 fps; / CVBS: PAL: 960H; NTSC: 960H
• Resolution : 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
• Day/Night : Auto(ICR)/Color/B/W
• BLC : BLC; HLC; DWDR
• WDR : DWDR
• White Balance : Auto Area white balance
• Gain Control : Auto
• Noise Reduction : 3D NR
• Illumination Mode  : Smart IR&WL; WL Mode; IR Mode
• Mirror : Yes
• Privacy Masking : Off/On (8 areas, rectangle)

Certification

• Certifications : CE-LVD: EN 62368-1; / CE-EMC: EN 55032; EN 55035; / FCC: 47 CFR FCC Part 15, Subpart B

Port

• Video Output : Video output choices of CVI/TVI/AHD/CVBS by one BNC port
• Audio Input : 1 channel

Power

• Power Supply : 12 VDC ± 30%
• Power Consumption : Max 2.6W (12 VDC, IR on)

Environment

• Operating Temperature : –40 °C to +60 °C
• Operating Humidity : <95% (RH), non-condensing
• Storage Temperature : –40 °C to +60 °C
• Storage Humidity : <95% (RH), non-condensing
• Protection :IP67

Structure

• Casing Material : Plastic
• Product Dimensions : 163.4 mm × 69.7 mm × 70 mm
• Net Weight : 0.18 kg
• Gross Weight : 0.26 kg
• Installation : Wall mount; ceiling mount; vertical pole mount

—
